Description

The ADM466C is a 4-pole RCBO with a 16A C-curve characteristic and 6 kA short-circuit breaking capacity. It provides 30mA Type A residual current protection across all four poles for three-phase plus neutral installations in commercial or light industrial environments.
Rated at 16A with a C-curve, this device suits three-phase socket outlet circuits or multi-phase loads where inrush current management is required. Combined four-pole protection in a single device simplifies panel design and reduces component count.
The ADM466C is DIN rail mountable in a 4-module format, IP20 rated, and operates at 230/400V AC. It is IEC 61009 compliant and RoHS certified.
