Description

The ABB S201C40 is a 1-pole Type C miniature circuit breaker rated at 40 A, forming part of ABB’s System pro M compact S200 series. It provides overload and short-circuit protection for single-phase circuits with Type C tripping characteristics, which deliver magnetic (instantaneous) disconnection for fault currents between 5 and 10 times the rated current. This characteristic is specifically suited to circuits supplying loads with higher inrush currents on energisation, such as motor loads, transformer primaries, fluorescent lighting with electromagnetic ballasts, and inductive heating equipment, where Type B MCBs might trip nuisance on switching.

The S201C40 complies with IEC 60898-1 and EN 60898-1 and is rated at 230/400 V AC with a short-circuit capacity of 6 kA at 230 V. The 17.5 mm per pole width enables space-efficient installation in compact distribution boards and consumer units. A visual trip indicator and rocker-type operating handle provide clear indication of tripped state and reliable manual switching. The device is suitable for use as the primary circuit protection device on branch circuits in commercial, industrial, and residential electrical distribution systems.

Compatible with the full range of ABB S200 series accessories, including auxiliary and alarm contact blocks, shunt and voltage releases, and RCD add-on modules from the DS200 family, the S201C40 supports the construction of advanced protection and monitoring assemblies within standard DIN rail boards. It is widely used in commercial and industrial distribution boards, machine control panels, motor feeder circuits, and control panel protection throughout Ireland and Europe, providing reliable overload and short-circuit protection tailored to the inrush characteristics of the circuits it protects.
