Description

The ADC410U is a compact single-module, single-pole RCBO rated at 10A with a C-curve tripping characteristic and 10 kA breaking capacity. It provides 30mA Type A residual current protection and replaces the previous ADA160U model in Hager’s product range.
The C-curve suits circuits where higher inrush currents occur on startup, such as motor loads or fluorescent lighting banks. Combined MCB and RCD functionality in a single module reduces installation complexity and saves panel space.
This device is suitable for Hager Type B distribution boards. It operates at 230/240V AC, is DIN rail mountable, IP20 rated, and RoHS compliant.
